Industrial Outdoor 5G Gateway

https://www.darkblueme.com/web/image/product.template/893/image_1920?unique=7175f19

3,675.00 AED 3675.0 AED 3,675.00 AED

3,675.00 AED

Not Available For Sale

(3,675.00 AED / Units)
  • Delivery

This combination does not exist.

5G Wi-Fi Router Industrial RS232 RS485

Terms and Conditions
Shipping: 45 Business Days


Hardware
CPUQuad-core ARM Cortex A7, 717MHz
RAM512MB
FLASH32MB+8GB eMMC
SD cardBuilt-in TF card slot
USBUSB2.0
Cellular Interface
Modem1 x 5G NR SA/NSA
Module Integrationm.2 or mini PCIe
Number of Antennas4
ConnectorSMA-K
SIM2 x Mini SIM (2FF)
Ethernet Interface
Number of Ports4 x 10/100/1000 Mbps, Gigabit Ethernet
Configuration4 x LAN or 3 x LAN + 1 x WAN
PoE OutputN/A
Wireless Interface
Standards802.11b/g/n/ac, AP or station modes
Frequency Bands2.4 GHz & 5GHz
Speed1167Mbps
SecurityWEP, WPA, WPA2
Encryption64/128 AES, TKIP
Antennas4
ConnectorSMA-K
GNSS Interface
Number of Antennas1 (only for GPS version)
ConnectorSMA-K with 50 ohms impedance
Dead ReckoningOptional
Seiral Interface
Type1 RS-232 + 1 RS-485 serial port
Socket Form1 * 7-pin 3.5 mm female socket
Signal DefinitionRX,TX,GND (RS-232) ,
A+,B-,GND (RS-485)
BaudrateRS-232 (300-115200bps)
RS-485 (300-115200bps)

ESD15KV
Software
Auto Fail-overBetween:
Cellular and WAN
WAN and Wi-Fi (station mode)
Cellular and Wi-Fi (station mode)
Network ProtocolsPPP,PPPoE,TCP,UDP,IPv4,IPv6,SSL,DHCP,ICMP, NAT,HTTP,HTTPs, DNS, ARP,NTP,Telnet, SSH, DDNS, etc.
RoutingStatic Routing, Policy routing, RIP, OSPF and BGP, etc
FirewallNAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List
VPNPPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN
Remote ManagementHTTP, Telnet, SSH, SMS
P V1/V2/V3, SNMP TRAP
Hongdian Wedora Cloud Platform
Serial Ports FunctionTransparent, Modbus RTU, etc
Power Supply and Consumption
Connector2 pin socket
Voltage Input+9V~+24V DC
Power ConsumptionIdle: 450mA@12V DC
Data transceiving: 2.2A@12V DC
Others
Reset ButtonYes
LED Indicators4 indicators for WiFi, SIG, NET, SYS
Hardware WatchdogYes
Physical Characteristics
Ingress ProtectionIP66
Housing & WeightMetal, 1860g
Dimension216×216×51.5(mm)
InstallationsDesktop, wall mounting and surface mounting
Operating Temperature-30 ~ +70℃
Storage Temperature-40 ~ +85 °C
Relative Humidity5 ~ 95%
CertificationsCE, FCC

Specifications
